Globe Valve, 150 LB, RF, ASME B16.10, ASTM A216 Gr WPB, Hand Wheel
د.إ355.13 – د.إ2,696.31
Quick Specs:
Globe Valve, NPS 1 (DN 25) Reduced Bore, Cl 150 (PN 20), RF (Raised Face), Straight pattern, bolted bonnet, OS&Y, A105N Body, Other Seal surface of disc, Other Seal surface of seat, Other Stem, Non renewable metal Seat, Handwheel Operation, Additional Info.: A105N +STL disc, STL+body seat, A182 F316 stem, F-F dimension 127mm, A193 B7&A194 2H+ZN bolting, Fire safe API 607/6FA, C.A.3mm Deviation : Reduced bore instead of Full bore
Globe Valve, NPS 4 (DN 100), Cl 150 (PN 20), RF (Raised Face), Straight pattern, bolted bonnet, OS&Y, A216 WCB Body, Other Seal surface of disc, Other Seal surface of seat, Other Stem, Non renewable metal Seat, Handwheel Operation, Additional Info.: A105N +STL disc, STL+body seat, A182 F316 stem, BS1873 design, F-F dimension 292mm, A193 B7&A194 2H+ZN bolting, Fire safe API607/6FA, C.A.3mm Deviation : Full bore instead of reduced bore
